HYDRAULIC HOSE REEL DRIVE SYSTEM (HHRDS)

The Federal Industries, Inc. HMA Servodrives utilize the company’s patented Variable Displacement Drive System (VDDS) hydraulic motor and controls technology. The HMA Servodrives are highly versatile and are utilized for various Aerial Refueling applications.

APPLICATIONS

Aerial Refueling Stores and Pods


Refueling Pumps

Hose and Drogue Units

Hose and Drogue Refueling


Tanker Internal Refueling Pumps

Hose and Drogue Units

Image by Felix
Image by Aleksei Zaitcev

EQUIPMENT PLATFORMS


FR-200 Hose Reel

FR-300 Hose Reel

FR-600 Hose Reel

KC-46A Hose Reel


Aerial Refueling Store/Pod Refueling Pumps

Refueling Boost Pumps

SPECIFICATIONS


Hydraulic Fluids: MIL-PRF-83282, Skydrol

Operational Pressures (psig): 3000 to 5000

Motor Displacements (Cu-In/Rev, 3000 psig): Up to 2.40


Motor Displacements (Cu-In/Rev, 5000 psig): Up to 1.20

Output Torque (In-Lbs max, 3000 psig): Up to 1150

Output Torque (In-Lbs max, 5000 psig): Up to 960

Output Speeds (RPM max): 0 to 13,000

Envelope: Varies based upon model (inquire)

Weight: Varies based upon model (inquire)

Image by Richard Cartmell

HMA
SERVODRIVE
COMPONENTS


Electrohydraulic Servovalve: Single or Dual Channel

Motor Swashplate Position Sensor: Single or Dual Channel Resolver

Motor Speed/Position Sensor: Single or Dual Channel Resolver

Integrated Isolation Valves: KC-46 configuration
